Model MA 02 -Automatic Horizontal Strapping Machines
Horizontal automatic strapping machines are highly-efficient and versatile machines that can be easily integrated into fully automated packaging internal lines. They secure the stack by performing one or several strap bindings around the stack which guarantee load stability, ease of storage and safety during transport. Automatic plastic strapping machines are developed using innovative technologies to prove a correct handling of the products in a wide diversity of industrial applications. The reliability of these machines and high-quality components guarantee maximum efficiency, durability and strenght that reduces all forms of maintenance to a minimum.
The range comprises totally automated models that are provided with a gliding frame. This allows the horizontal strapping of different dimensioned palletised loads in terms of width and length but also height. The operating system – with advancing movement of the head and guides – allows the packs to be compacted and strapped on 2 or 4 sides. The advantages of these pallet strapping machines are proven most often in food and beverage sectors. For the horizontal strapping of lighter loads, the available models are simple and dynamic machines to speed up the entire operation and bring increased perfomances in the internal flow.
- It works with polypropylene (PP) or polyester (PET) tape;
- Recommended for products placed on pallet packaging;
- Enables programming of several ways of packaging;
- Can be packed a wide range of products: wood, plastic, cans, textiles, metal, glass, electronic devices etc.
Dimensions: 3800 x 1380 x 400 mm
Tape width: 8-19 mm
Tape thickness: 0.60 -1.20 mm
Tape tensioning: 0-300 kg
Cutting speed: 2.4 – 5.5 m/ second
Operating cycle: 1-3 seconds
Installed power: 3 kW
